Description
The Notch 5/8″ Rigging Block is a medium-sized, lightweight arborist block designed to accommodate working lines up to 5/8” (16mm) in diameter.
Features:
- 25 kN WLL / 125 kN MBS
- Crafted with hot forged aluminium side plates featuring rope-friendly rounded cheeks
- Equipped with precision CNC machined aluminium sheaves, offering wide bend radii
- Features a low-profile, secure, and easy-to-open captive screw pin lock
- Enhanced anchor sling protection with high wall and full-diameter design
- Upper sheave designed to accept 1” anchor slings with a wide, concave shape
- Flared sideplates engineered to reduce twisting in complex rigging scenarios
Specifications:
- Working Load Limit: (WLL) 25 kN (5,620 lbs.)
- MBS: 125kN (28,100 lbs.)
- Max Working Line Diameter: 16mm
- Max Sling Diameter: 25mm
- Upper Sheave Diameter: 50mm
- Lower Sheave Diameter: 61mm
- Height: 158mm
- Width: 87mm
- Weight: 1.4 kg
- Sideplate Materials: Aluminium
- Sheave Material: Aluminium
- Axle Material: Stainless Steel
